Dang Steel, located in Da Nang, Vietnam, has built a solid reputation as a reliable manufacturer and supplier of top-notch steel materials, including SAE 1045 steel sheets and plates. Known for its precise processing and dedication to international standards, Dang Steel offers durable, high-performance carbon steel products that are perfect for tough industrial applications. SAE 1045 is a medium carbon steel celebrated for its impressive strength, hardness, and machinability. With a robust supply chain and a customer-centric approach, Dang Steel crafts customized solutions to meet the unique needs of the automotive, machinery, and construction sectors both in Vietnam and beyond.
SAE 1045 is a medium carbon steel characterized by a chemical composition of roughly 0.43–0.50% carbon, 0.60–0.90% manganese, ≤0.04% phosphorus, and ≤0.05% sulfur. It boasts high tensile strength (570–700 MPa), yield strength (≥330 MPa), and solid impact resistance. The steel typically has a Brinell hardness of about 170–210 HB when normalized. SAE 1045 is particularly well-suited for applications that demand moderate tensile strength and toughness. It responds effectively to heat treatment processes like hardening and tempering, enhancing its mechanical performance for critical engineering components.
| Specification | ASTM A830 AISI 1045, SAE 1045, |
| Grade | SAE J403 Grade 1045 |
| Condition | hot rolled or normalized |
| Width | Â 200 to 2000mm |
| Thickness | Â 6 to 800mm |
| Length | 2000 to 6000mm |
| Heat treated method | By flame or induction |
| MN | FE | S | C | P |
|---|---|---|---|---|
| 0.60 – 0.90% | 98.51 – 98.98% | ≤ 0.050% | 0.420 – 0.50% | ≤ 0.040% |
| MECHANICAL PROPERTIES | Â | Â |
|---|---|---|
| Â | Metric | Imperial |
| Tensile Strength, Ultimate | 565 MPa | 81,900 PSI |
| Tensile Strength, Yield | 310 MPa | 45,000 PSI |
| Modulus of Elasticity | 200 GPa | 29,000 KSI |
| Hardness, Brinell | 163 | 163 |
| Elongation at Break (in 50 mm) | 16.0% | 16.0% |
| Bulk Modulus (Typical for Steel) | 140 GPa | 20,300 KSI |
| Poissons Ratio | 0.290 | 0.290 |
| Shear Modulus | 80 GPa | 11,600 KSI |
| Grade | EU EN | DIN,WNr | JIS | AFNOR | BS | GOST | ISO | UNS |
| 1045 | C45E (1.1191) | Ck45 | S45C | XC45 XC48H1 | 080M46 CFS8 | 45 | C45E4 | G10450 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Length x Width | Thickness |
|---|---|
| mm | mm |
| 2000 x 1000 | 0.8 |
| 2440 x 1220 | 1.0 |
| 2500 x 1250 | 0.9 |
| 2500 x 1250 | 0.8 |
| 2000 x 1000 | 1.20 |
| 2000 x 1000 | 1.0 |
| 2000 x 1000 | 0.9 |
| 1830 x 1220 | 1.0 |
| 2500 x 1250 | 1.20 |
| Thickness | Length x Width | Mass per Sq m |
|---|---|---|
| mm | mm | Kg/m2 |
| 30.00 | 2000 x 1000 | 235.50 |
| 30.00 | 4000 x 2000 | 235.50 |
| 30.00 | 2500 x 1250 | 235.50 |
| 30.00 | 5000 x 2500 | 235.50 |
| 30.00 | 3000 x 1500 | 235.50 |
| 30.00 | 5000 x 1250 | 235.50 |
| 40.00 | 2000 x 1000 | 314.00 |
| 32.00 | 2000 x 1000 | 251.20 |
| 30.00 | 10000 x 2500 | 235.50 |
| 30.00 | 6000 x 2500 | 235.50 |
| 32.00 | 2500 x 1250 | 251.20 |
| 32.00 | 3000 x 1500 | 251.20 |
| 32.00 | 5000 x 2500 | 251.20 |
| 32.00 | 4000 x 2000 | 251.20 |
| 35.00 | 3000 x 1500 | 274.75 |
| 35.00 | 4000 x 2000 | 274.75 |
| 35.00 | 2500 x 1250 | 274.75 |
| 40.00 | 2500 x 1250 | 314.00 |
| 40.00 | 3000 x 1500 | 314.00 |
| 40.00 | 4000 x 2000 | 314.00 |
SAE 1045 steel sheets and plates find extensive use in applications that require greater strength and wear resistance compared to low carbon steels. They are perfect for manufacturing gears, axles, bolts, crankshafts, connecting rods, and hydraulic parts in the automotive and mechanical sectors. In construction and machinery, SAE 1045 is utilized for structural components, shafts, rolls, and parts for heavy-duty equipment. Its excellent machinability and heat treatment capabilities make it ideal for precision-engineered components. The combination of strength and toughness makes it a go-to choice for various demanding applications.
Dang Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Da Nang, Vietnam.
