Dang Steel, a trusted steel manufacturer and supplier based in Da Nang, Vietnam, provides a diverse selection of high-quality carbon steel products, including SAE 1020 tubing. Renowned for its reliability, cost-effectiveness, and performance, SAE 1020 tubing is a low-carbon steel that finds its place in various mechanical and structural applications. Dang Steel guarantees that all tubing products meet international standards, ensuring precise dimensions, top-notch surface quality, and dependable mechanical properties. With a commitment to timely delivery, technical support, and customer satisfaction, Dang Steel caters to a wide range of industries, including automotive, construction, and general engineering.
SAE 1020 is a low-carbon steel characterized by a chemical composition of roughly 0.18–0.23% carbon, 0.30–0.60% manganese, along with trace amounts of phosphorus (≤0.040%) and sulfur (≤0.050%). It boasts good ductility and weldability, with a tensile strength ranging from 410 to 510 MPa and a yield strength of about 245 MPa. This material offers excellent machinability in its cold-drawn or normalized state and has a Brinell hardness of approximately 111 HB. SAE 1020 tubing is perfect for forming, bending, and moderate-strength applications, making it a go-to choice for both mechanical and structural needs
| Grade: | ASME/ASTM SA179, SA192, SA210, SA178, SA214, API 5L |
|---|---|
| Size: | 1/8” NB TO 24” NB Sch 40/80/160/XXS |
| Form | Round, Square, Rectangular, Coil, U Tube, |
| Length | Single Random, Double Random & Required Length |
| End | Plain End, Bevelled End |
| Type | Seamless / ERW / Welded |
| Certification For Carbon | Mill Test Certificate as per EN 10204 / 3.2B |
| General Requirements | ASTM A 530/A 530M |
| Dimensional Tolerances | ANSI B 36.10 |
| OD Range | 1.250″ – 6.000″ (30-150mm) |
| Wall Range | 0.095″ – 1.000″ (.2.5-25mm) |
| Grade | C | Mn | Fe | P | S |
| AISI 1020 | 0.170 – 0.230 | 0.300 – 0.600 | 99.08 – 99.53 | ≤ 0.040 | ≤ 0.050 |
| Grade | Tensile Strength | Yield Strength | Elongation |
| SAE 1020 | 380 MPa, 55100 psi | 165 MPa, psi 29700 | 25 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
SAE 1020 tubing is commonly employed in applications that demand moderate strength, good formability, and outstanding weldability. Typical uses include mechanical tubing for automotive parts like axles, drive shafts, and engine components, as well as in general engineering for hydraulic systems, structural supports, and conveyor rollers. It’s also used in the construction of frames, agricultural machinery, and machine parts where cold-forming or machining is essential. The low carbon content of SAE 1020 tubing makes it particularly suitable for welding and case hardening processes, providing versatility in various applications.
Dang Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Da Nang, Vietnam.
