Dang Steel, a leading steel manufacturer and supplier located in Da Nang, Vietnam, is all about delivering high-quality J525 tubing for hydraulic and automotive uses. With a reputation for precision engineering and a commitment to international standards, Dang Steel offers seamless, cold-drawn, and annealed J525 tubing that boasts impressive dimensional accuracy and mechanical performance. Thanks to their state-of-the-art production facilities and robust distribution network, they provide reliable supply and tailored solutions for a variety of industries. Their J525 tubing is a favorite choice due to its clean internal finish, ability to handle high pressure, and excellent formability, making it perfect for demanding fluid and mechanical systems.
J525 tubing is crafted from low-carbon steel, usually containing Carbon (≤0.15%), Manganese (≤0.64–0.98%), Phosphorus (≤0.035%), and Sulphur (≤0.035%). The tubing undergoes cold-drawing and normalization processes to ensure a consistent grain structure and enhanced strength. It has a minimum yield strength of 241 MPa and a tensile strength that ranges from 365–483 MPa, along with good elongation and ductility. Known for its smooth internal surface finish, J525 tubing offers excellent bendability and outstanding performance in high-pressure hydraulic applications. Its mechanical reliability and resistance to corrosion make it a top choice for precision fluid transfer systems.
| Grade: | ASME/ASTM SA179, SA192, SA210, SA178, SA214, API 5L |
|---|---|
| Size: | 1/8” NB TO 24” NB Sch 40/80/160/XXS |
| Form | Round, Square, Rectangular, Coil, U Tube, |
| Length | Single Random, Double Random & Required Length |
| End | Plain End, Bevelled End |
| Type | Seamless / ERW / Welded |
| Certification For Carbon | Mill Test Certificate as per EN 10204 / 3.2B |
| General Requirements | ASTM A 530/A 530M |
| Dimensional Tolerances | ANSI B 36.10 |
| OD Range | 1.250″ – 6.000″ (30-150mm) |
| Wall Range | 0.095″ – 1.000″ (.2.5-25mm) |
| Carbon | 0.06 – 0.18 Max |
| Manganese | 0.30 – 0.60 |
| Phosphorus | .040 Max |
| Sulfur | 0.050 Max |
| Yield Strength, min | 170 MPa |
| Ultimate Strength, min | 310 MPa |
| Elongation in 50 mm, min | 35% |
| Hardness (Rockwell B), max | 65 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| TUBING WALL THICKNESS TOLERANCES | |||
|---|---|---|---|
| Nominal Wall Thickness (Inches) | Nominal Tube OD Through 1” (+/- Inches) | Nominal Tube OD Over 1” Through 2” (+/- Inches) | Nominal Tube OD Over 2” Through 4” (+/- Inches) |
| .028 (22 Ga) | .002/.003 | .003/.003 | .003/.003 |
| .035 (20 Ga) | .002/.004 | .002/.004 | .002/.004 |
| .042 (19 Ga) | .002/.004 | .002/.004 | .002/.005 |
| .049 (18 Ga) | .004/.005 | .003/.005 | .004/.008 |
| .058 (17 Ga) | .006/.006 | .004/.008 | .004/.008 |
| .065 (16 Ga) | .006/.006 | .004/.008 | .004/.008 |
| .072 (15 Ga) | .006/.010 | .006/.010 | .006/.010 |
| .083 (14 Ga) | .006/.010 | .006/.010 | .006/.010 |
| .095 (13 Ga) | .006/.010 | .006/.010 | .006/.010 |
| .100 | .006/.010 | .006/.010 | .006/.010 |
| .109 (12 Ga) | .006/.010 | .006/.010 | .006/.010 |
| .118 | .006/.010 | .006/.010 | .006/.010 |
| .120 (11 Ga) | .006/.010 | .006/.010 | .006/.010 |
| .134 (10 Ga) | .006/.010 | .006/.010 | .006/.010 |
| .148 (9 Ga) | — | .007/.001 | .007/.011 |
| .156 (5/32) | — | .007/.011 | .007/.011 |
| .165 (8 Ga) | — | .007/.011 | .007/.011 |
| .180 (7 Ga) | — | .007/.011 | .007/.011 |
| .197 | — | .008/0.12 | .008/0.12 |
| .203 (6 Ga) | — | .008/0.12 | .008/0.12 |
| .219 (7/32) | — | .008/.012 | .008/.012 |
| .236 | — | .014/.018 | .014/.018 |
| .238 (4 Ga) | — | .014/.018 | .014/.018 |
| .259 (3 Ga) | — | .014/.020 | .014/.020 |
J525 tubing finds its way into a wide range of hydraulic and fluid power systems, thanks to its impressive pressure-handling capabilities and formability. You’ll often see it in brake lines, fuel lines, transmission cooler lines, and power steering systems in the automotive industry. It’s also a go-to for industrial hydraulic circuits, compressors, and lubrication systems. The cold-drawn design and clean internal diameter make it perfect for flaring, bending, and forming without the worry of cracking. Its durability and reliability make it an essential component in various applications.
