Dang Steel, a well-respected manufacturer and supplier based in Da Nang, Vietnam, specializes in high-quality EN 10305-1 and EN 10305-4 Seamless Tubing that meets European standards. These precision-engineered steel tubes are celebrated for their exact dimensions, exceptional surface finish, and outstanding mechanical properties, making them ideal for critical industrial and engineering tasks. With state-of-the-art production facilities and rigorous quality control, Dang Steel guarantees durability, consistency, and top-notch performance. Their seamless tubing finds extensive use in hydraulic, automotive, mechanical, and structural applications, catering to both local and international markets with dependable solutions.
EN 10305-1 seamless tubes are cold-drawn precision tubes featuring smooth surfaces and tight dimensional tolerances, made from low-carbon steel that boasts excellent machinability and weldability. On the other hand, EN 10305-4 seamless tubes are tailored for hydraulic and pneumatic applications, providing high cleanliness, uniformity, and impressive pressure resistance. The mechanical properties of these grades include tensile strength ranging from 340 to 520 MPa, yield strength between 235 and 355 MPa, and elongation of 20 to 30%. Their composition, primarily iron with controlled amounts of carbon, manganese, and silicon, strikes a perfect balance between strength, ductility, and fatigue resistance.
| Steel Name | Steel Number | C max. | Si max. | Mn max. | P max. | S max. | AL min. |
| E215 | 1.0212 | 0.10 | 0.05 | 0.7 | 0.025 | 0.025 | 0.025 |
| 1.0308 | 0.17 | 0.35 | 1.2 | 0.025 | 0.025 | / | |
| E355 | 1.058 | 0.22 | 0.55 | 1.6 | 0.025 | 0.025 | / |
| Mechanical properties at room temperature | |||||||||||||
| Steel Grade | Minimum values for the delivery condition | ||||||||||||
| Steel Name | Steel Number | +C | +LC | +SR | +A | +N | |||||||
| Rm Mpa | A % | Rm Mpa | A % | Rm Mpa | ReH Mpa | A % | Rm Mpa | A % | Rm Mpa | ReH Mpa | A % | ||
| E215 | 1.0212 | 430 | 8 | 380 | 12 | 380 | 280 | 16 | 280 | 30 | 290 to 430 | 25 | 30 |
| E235 | 1.0308 | 480 | 6 | 420 | 10 | 420 | 350 | 16 | 315 | 25 | 340 to 480 | 235 | 25 |
| E355 | 1.0580 | 640 | 4 | 580 | 7 | 580 | 450 | 10 | 450 | 22 | 490 to 630 | 355 | 22 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Dang Steel is a leading manufacturer and distributor of high-quality EN10305-1 / EN10305-4 Seamless Tubing in Da Nang, Vietnam. We offer premium steel materials and a diverse range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to fast delivery and exceptional customer service, we source top-grade raw materials to ensure superior precision, strength, and durability for demanding industrial applications. Contact us today for all your EN10305-1 / EN10305-4 Seamless Tubing needs!
|
Hot rolled |
Outside Diameter, mm |
Tolerance, mm |
|
OD≤101.6 |
+0.4/-0.8 |
|
|
101.6＜OD≤177.8 |
+0.4/-1.2 |
|
|
Cold Drawn |
Outside Diameter, mm |
Tolerance, mm |
|
OD＜25.4 |
±0.10 |
|
|
25.4≤OD≤38.1 |
±0.15 |
|
|
38.1＜OD＜50.8 |
±0.20 |
|
|
50.8≤OD＜63.5 |
±0.25 |
|
|
63.5≤OD＜76.2 |
±0.30 |
|
|
76.2≤OD≤101.6 |
±0.38 |
|
|
101.6＜OD≤177.8 |
+0.38/-0.64 |
|
|
Hot rolled
|
Outside Diameter, mm |
Tolerance, % |
|
OD≤101.6, WT≤2.4 |
+40/-0 |
|
|
OD≤101.6, 2.4＜WT≤3.8 |
+35/-0 |
|
|
OD≤101.6, 3.8＜WT≤4.6 |
+33/-0 |
|
|
OD≤101.6, WT>4.6 |
+28/-0 |
|
|
OD>101.6, 2.4＜WT≤3.8 |
+35/-0 |
|
|
OD>101.6, 3.8＜WT≤4.6 |
+33/-0 |
|
|
OD>101.6, WT>4.6 |
+28/-0 |
|
|
Cold Drawn
|
Outside Diameter, mm |
Tolerance, % |
|
OD≤38.1 |
+20/-0 |
|
|
OD>38.1 |
+22/-0 |
EN 10305-1 / EN 10305-4 seamless tubing is widely utilized in industries that demand precision and reliability. In the automotive field, they are essential for fuel injection systems, steering components, and drive shafts. Hydraulic and pneumatic systems incorporate them in cylinders, pumps, and fluid power applications. Mechanical engineering relies on them for machinery parts, shafts, and structural supports. The construction and industrial sectors use them in load-bearing applications that require exact tolerances. Thanks to their smooth surface finish, dimensional accuracy, and durability, these seamless tubes are the go-to choice for high-performance, precision-critical applications.
