Dang Steel Manufacturer and Suppliers, located in Da Nang, Vietnam, has built a solid reputation in the steel industry by providing top-notch EN19 sheets and plates tailored for high-performance engineering needs. Renowned for their quality, precision, and commitment to international standards, Dang Steel offers EN19 products that are perfect for critical components in sectors like automotive, aerospace, and heavy machinery. With state-of-the-art processing facilities and a talented technical team, the company guarantees consistent mechanical properties, precise dimensions, and timely deliveries. Dang Steel remains a dependable partner for both local and global clients in search of durable alloy steel solutions.
EN19, also referred to as 709M40 or AISI 4140, is a high-tensile alloy steel that contains around 0.35–0.45% carbon, 0.70–1.00% manganese, 0.15–0.35% silicon, 0.80–1.10% chromium, and 0.15–0.25% molybdenum. It boasts a tensile strength ranging from 850–1000 MPa and a yield strength of 680–880 MPa when heat-treated. EN19 steel is known for its remarkable toughness, good ductility, and impressive fatigue strength. Dang Steel provides EN19 sheets and plates in various conditions—normalized, quenched, or tempered—ensuring they meet the high-performance demands of engineering applications.
Grade : EN19 Low Alloy Steel Plate
Thickness : from 3mm up to as thick as 150mm
Length :3000mm-18000mm
Supply Condition : As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement.
Impact tested : -52° C
Process of Manufacturing : Hot-Rolled (HR)
| Â Grade | Mn | Si | C | Cr | P | Ni | S | Mo |
| EN – 19 | .50 – .80 | .10 – .35 | .35 – .45 | .90 – 1.40 | .040 | – | .040 | .20 – .40 |
| Max Stress | 850-1000 n/mm2 | |
| Impact KCV | 55 Joules Min | |
| Hardness | 248-302Â HB | |
| Yield Stress | 700Â N/mm2Â Min | |
| 0.2% Proof Stress | 680Â N/mm2Â Min | Â subject to ruling section |
| Elongation | 9% Min |
| GRADE | BS 970 1991 | BS 970 1955 EN | AISI/SAE | Werkstoff |
| EN 19 | 708M40 | EN19 | 4140 | 1.7225 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
EN19 sheets and plates find extensive use in industries that require exceptional tensile strength, toughness, and resistance to wear and fatigue. They are commonly used in the production of gears, high-strength bolts, drive shafts, axles, spindles, studs, and components for machine tools. Thanks to its outstanding hardenability and impact resistance, EN19 is well-suited for applications that experience dynamic and torsional stress. In sectors like automotive, oil and gas, and general engineering, EN19 consistently delivers reliable performance even under challenging conditions. Dang Steel’s EN19 products are meticulously engineered to meet these rigorous demands.
