Dang Steel, a reputable manufacturer and supplier located in Da Nang, Vietnam, is dedicated to delivering top-notch DILLIDUR 400V Sheets and Plates tailored to meet a variety of industrial needs. Renowned for their exceptional durability, toughness, and wear resistance, these plates are a go-to choice for industries that require dependable performance in extreme conditions. Dang Steel takes pride in ensuring that every DILLIDUR 400V product is meticulously sourced and processed according to strict quality standards, providing clients with cost-effective solutions for heavy-duty applications in construction, mining, quarrying, and material handling sectors, both locally and internationally.
The DILLIDUR 400V Sheets and Plates are crafted from high-quality alloyed steel, incorporating elements like carbon, manganese, chromium, and nickel. This carefully balanced mix enhances hardness and strength while still allowing for good weldability and formability. With a nominal hardness of about 400 HBW, these plates are designed to offer outstanding wear resistance. They also boast excellent impact toughness, ensuring they hold up well in demanding environments where abrasion and mechanical stress are prevalent, making them perfect for heavy-duty structural and wear applications.
Item: Dillidur 400V
Thickness : 5mm to 150mm
Length : 6,000mm to 12,000mm
Width : 1,500mm to 2,500mm
Heat Treatment: N, Q+T
Surface Point : PVDF, PE, HDP, SMP, EP
| C | Si | Mn | P | S | Mo | Ni | Cr | V | Nb | B |
| ≤ 0.20 | ≤ 0.50 | ≤ 1.80 | ≤ 0.025 | ≤ 0.010 | ≤ 0.50 | ≤ 0.80 | ≤ 1.50 | ≤ 0.08 | ≤ 0.05 | ≤ 0.005 |
| Grade | Mechanical Property | Charpy V Impact Test | |||
| DILIDUR 400V | Yield | Tensile | Elongation | Degree | longitudinal |
| Min Mpa | Mpa | Min % | -40 | J | |
| 1000 | 1250 | 10 | 45 | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| 1/8″ | 3/8″ | 3/4″ | 1-1/2″ | 3″ |
| 3/16″ | 1/2″ | 1″ | 2″ | 4″ |
| 1/4″ | 5/8″ | 1-1/4″ | 2-1/2″ | Â |
| *1/8″ thick plate is available in one size only 60″x 120″. The 3/6″ thick plate is available only as 48″ x 144″ and 96″ x 144″. | ||||
| Thickness | Width | Length |
| 4 | 2000 | 6000 |
| 5 | 2000 | 6000 |
| 6 | 2000 | 6000 |
| 6 | 2500 | 6000 |
| 8 | 2000 | 6000 |
| 8 | 2500 | 6000 |
| 10 | 2000 | 6000 |
| 12 | 2000 | 6000 |
| 15 | 2000 | 6000 |
| 16 | 2000 | 6000 |
| 20 | 2000 | 6000 |
| 25 | 2000 | 6000 |
| 32 | 2000 | 6000 |
| 40 | 2000 | 6000 |
| 50 | 2000 | 6000 |
| 60 | 1800 | 3400 |
Dang Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Da Nang, Vietnam.
