Dang Steel, a reputable manufacturer and supplier based in Da Nang, Vietnam, specializes in providing top-notch Carbon Steel JIS G3445 Pipes tailored to meet a variety of industrial needs. These pipes are well-known for their durability, precision, and adherence to international standards. With a commitment to excellence in production processes, Dang Steel delivers pipes that are ideal for both mechanical and structural applications. Thanks to their state-of-the-art facilities and rigorous quality control measures, the company offers dependable solutions for the construction, machinery, and automotive industries. The JIS G3445 pipes are particularly noted for their impressive strength, machinability, and extended service life, making them a great choice for industries that prioritize both performance and cost-effectiveness.
Carbon Steel JIS G3445 Pipes are made up of a blend of carbon, manganese, phosphorus, sulfur, and silicon, which together provide outstanding mechanical strength and workability. The carbon content boosts toughness and durability, while manganese enhances wear resistance. These pipes boast a tensile strength between 440 MPa and 570 MPa, with a yield strength exceeding 275 MPa, ensuring they can handle significant loads. With good elongation and impact resistance, JIS G3445 pipes maintain their shape and stability even under stress. Their well-balanced chemical makeup and mechanical properties make them ideal for machining, welding, and forming across various industrial applications.
| Standard | : | JIS G3445 |
| Description Name | : | STKM 11A Steel tube, STKM 12A steel tubes, STKM 12C steel tubes, STKM 13A steel tubes, STKM 13C steel tubes |
| Size | : | 6mm-340mm |
| Wall Thickness | : | 1mm-50mm |
| Shape | : | Round |
| Production Type | : | Cold drawn, cold rolled or hot rolled |
| Length | : | Single random length/ Double random length or as customer’s actual request max length is 10m |
| Grade | : | STKM 11A, STKM 12A, STKM 12C, STKM 12B, STKM 13A, STKM 13B, STKM 13C, STKM 15A, STKM 17A |
| C | Si | Mn | P | S |
| max  0.12 | max  0.35 | max  0.6 | max  0.04 | max  0.04 |
| Assortment | Yield point or Proof stress | Tensile strength | Elongation | Reduction of area | Charpy impact strength |
| – | N/mm 2 | N/mm 2 | % | % | J/cm 2 |
| Tubes | Â | 290 | 35 | Â | Â |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Dang Steel is a trusted manufacturer and supplier of high-quality Carbon Steel JIS G3445 Pipe products in Da Nang, Vietnam. Specializing in premium steel materials, we offer a diverse range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a strong commitment to timely delivery and exceptional customer service, Dang Steel ensures the supply of top-grade materials that deliver superior performance in various industrial applications. Trust Dang Steel for all your Carbon Steel JIS G3445 Pipe needs.
| Permissible Specified Outside Diameter and Specified Wall Thickness | ||
| Specified Outside Diameter D mm (in.) | Specified Wall Thickness t mm (in.) | |
| Special Light Sizes a | Regular Sizes | |
| ≥ 10.3 (0.405) to < 13.7 (0.540) | — | ≥ 1.7 (0.068) to ≤ 2.4 (0.094) |
| ≥ 13.7 (0.540) to < 17.1 (0.675) | — | ≥ 2.2 (0.088) to ≤ 3.0 (0.118) |
| ≥ 17.1 (0.675) to < 21.3 (0.840) | — | ≥ 2.3 (0.091) to ≤ 3.2 (0.125) |
| ≥ 21.3 (0.840) to < 26.7 (1.050) | — | ≥ 2.1 (0.083) to ≤ 7.5 (0.294) |
| ≥ 26.7 (1.050) to < 33.4 (1.315) | — | ≥ 2.1 (0.083) to ≤ 7.8 (0.308) |
| ≥ 33.4 (1.315) to < 48.3 (1.900) | — | ≥ 2.1 (0.083) to ≤ 10.0 (0.394) |
| ≥ 48.3 (1.900) to < 60.3 (2.375) | — | ≥ 2.1 (0.083) to ≤ 12.5 (0.492) |
| ≥ 60.3 (2.375) to < 73.0 (2.875) | ≥ 2.1 (0.083) to ≤ 3.6 (0.141) | > 3.6 (0.141) to ≤ 14.2 (0.559) |
| ≥ 73.0 (2.875) to < 88.9 (3.500) | ≥ 2.1 (0.083) to ≤ 3.6 (0.141) | > 3.6 (0.141) to ≤ 20.0 (0.787) |
| ≥ 88.9 (3.500) to < 101.6 (4.000) | ≥ 2.1 (0.083) to ≤ 4.0 (0.156) | > 4.0 (0.156) to ≤ 22.0 (0.866) |
| ≥ 101.6 (4.000) to < 168.3 (6.625) | ≥ 2.1 (0.083) to ≤ 4.0 (0.156) | > 4.0 (0.156) to ≤ 25.0 (0.984) |
| ≥ 168.3 (6.625) to < 219.1 (8.625) | ≥ 2.1 (0.083) to ≤ 4.0 (0.156) | > 4.0 (0.156) to ≤ 40.0 (1.575) |
| ≥ 219.1 (8.625) to < 273.1 (10.750) | ≥ 3.2 (0.125) to ≤ 4.0 (0.156) | > 4.0 (0.156) to ≤ 40.0 (1.575) |
| ≥ 273.1 (10.750) to < 323.9 (12.750) | ≥ 3.6 (0.141) to ≤ 5.2 (0.203) | > 5.2 (0.203) to ≤ 45.0 (1.771) |
| ≥ 323.9 (12.750) to < 355.6 (14.000) | ≥ 4.0 (0.156) to ≤ 5.6 (0.219) | > 5.6 (0.219) to ≤ 45.0 (1.771) |
| ≥ 355.6 (14.000) to < 457 (18.000) | ≥ 4.5 (0.177) to ≤ 7.1 (0.281) | > 7.1 (0.281) to ≤ 45.0 (1.771) |
| ≥ 457 (18.000) to < 559 (22.000) | ≥ 4.8 (0.188) to ≤ 7.1 (0.281) | > 7.1 (0.281) to ≤ 45.0 (1.771) |
| ≥ 559 (22.000) to < 711 (28.000) | ≥ 5.6 (0.219) to ≤ 7.1 (0.281) | > 7.1 (0.281) to ≤ 45.0 (1.771) |
| ≥ 711 (28.000) to < 864 (34.000) | ≥ 5.6 (0.219) to ≤ 7.1 (0.281) | > 7.1 (0.281) to ≤ 52.0 (2.050) |
| ≥ 864 (34.000) to < 965 (38.000) | — | ≥ 5.6 (0.219) to ≤ 52.0 (2.050) |
| ≥ 965 (38.000) to < 1422 (56.000) | — | ≥ 6.4 (0.250) to ≤ 52.0 (2.050) |
| ≥ 1422 (56.000) to < 1829 (72.000) | — | ≥ 9.5 (0.375) to ≤ 52.0 (2.050) |
| ≥ 1829 (72.000) to < 2134 (84.000) | — | ≥ 10.3 (0.406) to ≤ 52.0 (2.050) |
In the realm of mechanical and structural engineering, Carbon Steel JIS G3445 Pipes are widely utilized due to their strength and adaptability. They find extensive use in the production of automotive components, machine parts, agricultural equipment, and bicycles. These pipes are also perfect for shafts, frames, and other precision mechanical parts that demand high machinability and durability. In construction, they serve as essential elements for load-bearing structures, frameworks, and support systems. Their excellent weldability and high performance make them a go-to choice for many applications.
Dang Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Da Nang, Vietnam.
