Introducing Dang Steel, a well-respected manufacturer and supplier based in Da Nang, Vietnam, that specializes in top-notch Carbon Steel F56 Forged Fittings tailored for tough industrial applications. With state-of-the-art manufacturing facilities and a commitment to international standards, Dang Steel produces fittings that guarantee strength, precision, and a long lifespan. These forged fittings are designed to endure high pressure, temperature changes, and corrosive environments, making them incredibly reliable. The company’s dedication to quality, durability, and prompt delivery has built a solid reputation in global markets, serving sectors like oil, gas, petrochemicals, and power generation.
When it comes to composition and mechanical properties, Carbon Steel F56 Forged Fittings are primarily made up of carbon, manganese, phosphorus, sulfur, silicon, and a few trace alloying elements that boost toughness and weldability. They boast impressive mechanical properties, including excellent tensile strength, good yield strength, and high impact resistance, ensuring dependable performance under pressure. Plus, they offer good hardness, durability, and wear resistance, making them perfect for heavy-duty applications. The F56 grade fittings also provide decent ductility and weldability, which simplifies fabrication and installation. Their well-balanced mechanical strength and chemical makeup ensure they perform consistently in challenging environments.
Standard : ASTM A694 / ASME SA 694
Dimensions : ASME/ANSI 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8″ NB to 4″ NB
Type : Socketweld Fittings, Screwed-Threaded Fittings (NPT or PT Type)
Rating Pressure : Threaded End – 2000 /3000/ 6000 LBS. Socket-weld End – 3000 / 6000/ 9000 LBS.
| Grade | C | Si | Mn | P | S | Mo | Ni | Cr | Cu | V | Nb |
| F56 | 0.17-0.23 | 0.15-0.40 | 1.30-1.60 | ≤ 0.025 | ≤ 0.015 | 0.45-0.65 | ≤ 0.30 | ≤ 0.30 | ≤ 0.25 | – | 0.025~0.050 |
| Grade | Yield Strength, Min (KSI ) | Tensile Strength, Min (KSI) |
| A694 | 65 | 77 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| ASME B16.11 | Factory-Made Wrought Socketweld Fittings | CS F56 Forged Screwed Elbows, Street Elbow, Carbon Steel F56 Screwed Unequal Tee, Steel Straight Tee, Carbon Steel F56 Reducing Coupling, Carbon Steel F56 Hex Plug, Forged Straight Tees, Socket Weld Pipe Cap, Forged Pipe Cap, Equal Crossess, CS F56 Threaded Bushing, Carbon Steel F56 Screwed Caps, Swedge Nipples |
| MSS-SP-79 | standard Practice covers ratings, tolerances, finish, dimensions, marking and material requirements for socket-welding | Carbon Steel F56 Barrel Nipples, CS F56 Forged Threaded Boss, Carbon Steel F56 Forged Hex Head Bull Plugs |
| MSS-SP-83 | Forged and Fabricated Socket-Welding Fittings for Low Pressure, Corrosion Resistant Applications | Carbon Steel F56 High Quality Socket weld 90° Elbow, Straight and Reducing-on-the-Tees, Forged 45° Short Radius Elbow, CS F56 caps, 3000LB Socket Weld Cross |
| MSS-SP-95 | Integrally Reinforced Forged Fittings – Socket Welding, Threaded, and Buttwelding Ends | CS F56 Socket weld Long Radius 90 Degree Elbows, Reducing Nipple, Socket weld Bushing, Threaded Plug, End Pipe caps, Carbon Steel F56 Coupling |
In terms of uses and applications, Carbon Steel F56 Forged Fittings are a go-to choice in industries that need strong and leak-proof piping connections. You’ll find them commonly used in oil and gas refineries, chemical plants, petrochemical industries, and power generation facilities where high-pressure and high-temperature operations are the norm. These fittings are perfect for connecting, redirecting, or controlling fluid flow in pipelines. Their strength and wear resistance make them ideal for offshore drilling, marine engineering, and hydraulic systems. Additionally, they find applications in construction, ensuring robust and reliable connections wherever they’re needed.
Dang Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Da Nang, Vietnam.
