Dang Steel, a prominent manufacturer and supplier in Da Nang, Vietnam, specializes in high-quality Carbon Steel EN-42 Bars. Known for their precision, durability, and reliable performance, Dang Steel meets a variety of industrial demands by offering a broad selection of EN-42 bar sizes and grades. With a strong focus on quality, cutting-edge production methods, and strict compliance with international standards, Dang Steel guarantees products that fulfill both local and global needs. Trusted by sectors like engineering, automotive, and manufacturing, their EN-42 bars are perfect for applications that require strength, toughness, and wear resistance, making Dang Steel a go-to partner for steel solutions.
Carbon Steel EN-42 Bars mainly contain 0.38–0.45% carbon and 0.60–0.90% manganese, along with small amounts of phosphorus and sulfur. This specific alloy mix delivers outstanding hardness, tensile strength, and toughness, making it ideal for heavy-duty uses. EN-42 bars can be heat-treated through processes like quenching and tempering to boost their mechanical properties. Typical characteristics include a tensile strength of about 700–850 MPa, yield strength around 450–600 MPa, and elongation of 12–18%, providing a well-rounded blend of ductility and wear resistance for various industrial applications.
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Round Bars | 3.0 – 50.8 mm, Over 50.8 – 300mm |
| Rectangular Bars | 6.35 x 12.7mm,6.35 x 25.4mm,12.7 x 25.4mm |
| Hex Bars | AF5.8mm–17mm |
| Square Bars | AF2mm – 14mm, AF6.35mm,9.5mm,12.7mm, 15.98mm,19.0mm, 25.4mm |
| Flat Bars | 1/2” to 10” in thickness range of 2mm to 150mm, |
| Finish | Bright, Polish & Black |
| Length | 1 to 6 Meters, Custom Cut Lengths |
| Form | Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc. |
Grade | Chemical composition %: | |||||||
| C | Si | Mn | S | P | Cr | Ni | Cu | |
| En42 | 0.17-0.24 | 0.17-0.37 | 0.7-1.00 | ≤0.035 | ≤0.035 | ≤0.25 | ≤0.25 | ≤0.25 |
| Chemical Composition | Application | |||||||||
| C | Si | Mn | P≤ | S≤ | CU≤ | Cr | Ni | Mo | V | |
| 0.43-0.49 | 0.15-0.35 | 0.60-0.90 | 0.03 | 0.035 | machine structural use, hand tools | |||||
| 0.53-0.59 | 0.17-0.37 | 0.50-0.80 | 0.03 | 0.03 | 0.2 | 0.25 | 0.3 | hand tools | ||
| 0.57-0.63 | 0.17-0.37 | 0.50-0.80 | 0.03 | 0.03 | 0.2 | 0.25 | 0.3 | hand tools | ||
| 0.13-0.18 | 0.15-0.35 | 0.60-0. | ||||||||
ULTIMATE TENSILE STRENGTH, S. (MPA) | 621 |
|---|---|
Modulus of elasticity, E (Gpa) | 204 |
Fatigue strength coefficient, of (Mpa) | 948 |
Fatigue strength exponent, b | -0.092 |
Fatigue ductility coeffient ,ef | 0.26 |
Fatigue ductility exponent,c | -0.445 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Size Table in MM | Chucked true to Outside Dia in MM | Chucked true to Inside Dia in MM and Inch | |||||||
|---|---|---|---|---|---|---|---|---|---|
| Outside Dia, Milimeter | Inside Dia, Milimeter | Maximum Outside Dia, Milimeter | Minimum. Inside Dia, Milimeter | Maximum Outside Dia, Inches. | Minimum. Inside Dia, Inches | Maximum Outside Dia, Milimeter | Minimum. Inside Dia, Milimeter | Maximum Outside Dia, Inches | Minimum. Inside Dia, Inches |
| 32 | 20 | 31 | 21.9 | 1.220 | 0.862 | 30 | 21 | 1.185 | 0.827 |
| 32 | 16 | 31 | 18 | 1.220 | 0.709 | 30 | 17 | 1.181 | 0.669 |
| 36 | 25 | 35 | 26.9 | 1.378 | 1.059 | 34.1 | 26 | 1.343 | 1.024 |
| 36 | 20 | 35 | 22 | 1.378 | 0.866 | 34 | 21 | 1.339 | 0.827 |
| 36 | 16 | 35 | 18.1 | 1.378 | 0.713 | 33.9 | 17 | 1.335 | 0.669 |
| 40 | 28 | 39 | 29.9 | 1.535 | 1.177 | 38.1 | 29 | 1.500 | 1.142 |
| 40 | 25 | 39 | 27 | 1.535 | 1.063 | 38 | 26 | 1.496 | 1.024 |
| 40 | 20 | 39 | 22.1 | 1.535 | 0.870 | 37.9 | 21 | 1.492 | 0.827 |
| 45 | 32 | 44 | 33.9 | 1.732 | 1.335 | 43.1 | 33 | 1.697 | 1.299 |
| 45 | 28 | 44 | 30 | 1.732 | 1.181 | 43 | 29 | 1.693 | 1.142 |
| 45 | 20 | 44 | 22.2 | 1.732 | 0.874 | 42.8 | 21 | 1.685 | 0.827 |
| 50 | 36 | 49 | 38 | 1.929 | 1.496 | 48 | 37 | 1.890 | 1.457 |
| 50 | 32 | 49 | 34.1 | 1.929 | 1.343 | 47.9 | 33 | 1.886 | 1.299 |
| 50 | 25 | 49 | 27.2 | 1.929 | 1.071 | 47.8 | 26 | 1.882 | 1.024 |
| 56 | 40 | 55 | 42 | 2.165 | 1.654 | 54 | 41 | 2.126 | 1.614 |
| 56 | 36 | 55 | 38.1 | 2.165 | 1.500 | 53.9 | 37 | 2.122 | 1.457 |
| 56 | 28 | 55 | 30.3 | 2.165 | 1.193 | 53.7 | 29 | 2.114 | 1.142 |
| 63 | 50 | 62 | 51.9 | 2.441 | 2.043 | 61.1 | 51 | 2.406 | 2.008 |
| 63 | 45 | 62 | 47 | 2.441 | 1.850 | 61 | 46 | 2.402 | 1.811 |
| 63 | 40 | 62 | 42.2 | 2.441 | 1.661 | 60.8 | 41 | 2.394 | 1.614 |
| 63 | 36 | 62 | 38.3 | 2.441 | 1.508 | 60.7 | 37 | 2.390 | 1.457 |
| 63 | 32 | 62 | 34.4 | 2.441 | 1.354 | 60.6 | 33 | 2.386 | 1.299 |
| 71 | 56 | 69.9 | 58 | 2.752 | 2.283 | 68.9 | 57 | 2.713 | 2.244 |
| 71 | 45 | 69.9 | 47.3 | 2.752 | 1.862 | 68.6 | 46 | 2.701 | 1.811 |
| 71 | 40 | 69.9 | 42.4 | 2.752 | 1.669 | 68.5 | 41 | 2.697 | 1.614 |
| 71 | 36 | 69.9 | 38.5 | 2.752 | 1.516 | 68.4 | 37 | 2.693 | 1.457 |
| 75 | 60 | 73.8 | 62 | 2.906 | 2.441 | 72.8 | 61 | 2.866 | 2.402 |
| 75 | 50 | 73.8 | 52.2 | 2.906 | 2.055 | 72.6 | 51 | 2.858 | 2.008 |
| 75 | 40 | 73.8 | 42.5 | 2.906 | 1.673 | 72.3 | 41 | 2.846 | 1.614 |
| 80 | 63 | 78.8 | 65 | 3.102 | 2.559 | 77.8 | 64 | 3.063 | 2.520 |
| 80 | 50 | 78.8 | 52.4 | 3.102 | 2.053 | 77.4 | 51 | 3.047 | 2.008 |
| 80 | 45 | 78.8 | 47.5 | 3.102 | 1.870 | 77.3 | 46 | 3.043 | 1.811 |
| 80 | 40 | 78.8 | 42.6 | 3.102 | 1.677 | 77.2 | 41 | 3.039 | 1.614 |
| 85 | 67 | 83.7 | 69.1 | 3.295 | 2.720 | 82.6 | 68 | 3.252 | 2.677 |
| 85 | 55 | 83.7 | 57.4 | 3.295 | 2.260 | 82.3 | 56.0 | 3.240 | 2.205 |
| 85 | 45 | 83.7 | 47.6 | 3.295 | 1.874 | 82.1 | 46.0 | 3.232 | 1.811 |
| 90 | 71 | 88.6 | 73.1 | 3.488 | 2.878 | 87.6 | 72.1 | 3.449 | 2.839 |
Carbon Steel EN-42 Bars find extensive use in industries that demand high-strength and durable steel components. They are commonly used to manufacture gears, shafts, axles, bolts, and studs, as well as parts for automotive and heavy machinery. Their remarkable toughness and wear resistance make them suitable for engineering tools, construction equipment, and industrial machinery that face high stress and impact. Additionally, EN-42 bars are utilized in fabrication processes that require precise machining and heat treatment for enhanced performance.
Dang Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Da Nang, Vietnam.
