Dang Steel, a reputable manufacturer and supplier located in Da Nang, Vietnam, is dedicated to providing top-notch Carbon Steel EN 10210-1 Grade S235JRH Pipes. These pipes are crafted in line with European standards, guaranteeing durability, reliability, and performance across various industries. With state-of-the-art production facilities and rigorous quality control measures, Dang Steel delivers both seamless and welded pipe solutions that cater to a wide range of structural and engineering needs. Renowned for their exceptional strength, precise dimensions, and resistance to corrosion, these pipes are extensively utilized in infrastructure, construction, and industrial applications, making Dang Steel a trusted partner for all carbon steel piping requirements.
Carbon Steel EN 10210-1 Grade S235JRH Pipes are mainly made up of carbon, manganese, silicon, along with small amounts of sulfur and phosphorus, resulting in a well-balanced chemical composition. They boast a minimum yield strength of 235 MPa and a tensile strength that ranges from 360 to 510 MPa, ensuring they are tough and reliable. With impressive impact resistance even at low temperatures, they meet the JRH impact testing standards. The material is also known for its good weldability and machinability, making it perfect for structural applications. Its mechanical properties strike a great balance between strength, ductility, and performance in challenging construction and engineering settings.
| Property | Specification |
|---|---|
| Dimensional Tolerances | Thickness: All sizes +/- 10% |
| Type | Seamless, Welded, ERW |
| Length | 6000 – 14000 mm |
| Surface Protection | Black (Self-Colored, Uncoated), Varnish/Oil Coating, Pre-Galvanized, Hot Dip Galvanized |
| Wall Thickness | 0.5 mm – 25 mm |
| Standard | BS EN 10210 – Hot Finished Structural Hollow Sections of Non-Alloy and Fine Grain Steels |
| SHS (Square Hollow Sections) Sizes | 20 x 20 mm – 400 x 400 mm |
| Grade | S235JRH |
| Dimension Range | 21.3 mm – 914 mm |
| Packing | In bundles, Anti-corrosion heat preservation, Varnish coating, Ends can be bevelled or square cut, End capped, Certification & supplementary test, Finishing & Identity Mark |
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
|---|---|---|---|---|---|---|---|---|---|
| max 0.17 | – | max 1.40 | 0.045 | 0.045 | – | – | – | – | N0.009 |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| 340 | 470 | – | 26 | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Dang Steel is a trusted manufacturer and supplier of high-quality Carbon Steel EN 10210-1 Grade S235JRH Pipe in Da Nang, Vietnam. Specializing in premium steel materials, we offer a diverse range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a strong commitment to reliable delivery and exceptional customer service, Dang Steel provides top-grade materials that ensure superior performance in various industrial applications. Trust Dang Steel for all your Carbon Steel EN 10210-1 Grade S235JRH Pipe needs.
| 1/8″ IPS(.405″ O.D.) | 3 1/2″ IPS( 4.000″ O.D.) |
|---|---|
| SCH 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/4″ IPS(.540″ O.D.) | 4″ IPS(4.500″ O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 3/8″ IPS(.675″ O.D.) | 5″ IPS( 5.563″ O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/2″ IPS(.840″ O.D.) | 6″ IPS(6.625″ O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 3/4″ IPS(1.050″ O.D.) | 8 ” IPS(8.625″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 1″ IPS:(1.315′ O.D.) | 10″ IPS(10.750″ O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 10, 20, 40, 80 (.500), TRUE 80(.500) |
| 1-1/4″ IPS(1.660″ O.D.) | 12″ IPS(12.750″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 10, 20, 40(.375), TRUE40(.406), SCH80(.500) |
| 1-1/2″ IPS(1.900″ O.D.) | 14″ IPS(14.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10 (.188), SCH40 (.375) |
| 2″ IPS(2.375″ O.D.) | 16″ IPS(16.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10(.188), SCH40(.375) |
| 2 1/2″ IPS(2.875″ O.D.) | 18″ IPS (18.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH-40 (.375) |
| 3″ IPS( 3.500″ O.D.) | |
| SCH 5, 10, 40, 80, 160, XXH |
| Outer diameter and wall Thickness | |||
|---|---|---|---|
| Execution | Size Range | OD Tolerance | Wall tolerance |
| Hot-rolled Tube | OD – 80 mmOD > 80 mmWall < 12 mmWall – 12 mm | ± 0.4 mm± 0.5 % of OD | ± 0.7 mm± (5 % x wallthickness + 0.1 mm |
| Hot-rolled peeled tube | All sizesWall < 12 mmWall – 12 mm | + 0.25/- 0 mm | ± 0.8 mm± (5 % x wall thickness+ 0.2 mm) |
| Cold Worked tubecold-rolled or cold-drawn | OD < 40 mmOD 40 – 80 mmOD > 80 Wall Thickness< 6 mm Wall Thickness6 – 8 mm Wall Thickness > 8 | + 0.30/- 0 mm*+ 0.35/- 0 mm*+ 0.40/- 0 mm* | ± 0.30 mm± 0.35 mm± 0.40 mm |
Carbon Steel EN 10210-1 Grade S235JRH Pipes find extensive use in the structural and engineering sectors thanks to their strength and toughness. They are perfect for construction frameworks, bridges, and industrial buildings, providing excellent load-bearing capabilities. These pipes are also utilized in the creation of mechanical structures, transmission towers, and transport equipment. Their weldability and durability make them a go-to choice for offshore structures, pipelines, and energy plants. Additionally, they are well-suited for various other applications, ensuring they meet the diverse needs of the industry.
Dang Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Da Nang, Vietnam.
