Dang Steel, a reputable manufacturer and supplier located in Da Nang, Vietnam, is dedicated to providing top-notch Carbon Steel API X52 5L PSL 2 Pipes that adhere to international quality standards. With a keen emphasis on durability, precision, and reliability, Dang Steel caters to industries that need strong piping solutions for high-pressure and high-temperature applications. These pipes are well-known for their exceptional strength, resistance to corrosion, and consistent performance in critical settings. Dang Steel guarantees prompt delivery, competitive pricing, and strict adherence to global specifications, making them a trustworthy partner for infrastructure and energy projects.
Carbon Steel API X52 5L PSL 2 Pipes are mainly made up of carbon, manganese, phosphorus, sulfur, vanadium, niobium, and titanium, all in carefully controlled amounts. This specific blend boosts their weldability, toughness, and wear resistance. The pipes have a minimum yield strength of 52,000 PSI (360 MPa) and a tensile strength that starts at 66,000 PSI (455 MPa) and goes up from there. They exhibit excellent hardness, elongation, and impact resistance, making them ideal for challenging industrial environments. The mechanical properties are fine-tuned to ensure durability, reliability, and efficiency even under extreme pressure and temperature conditions in various critical applications.
| Grade of material | X52 / L390 (N, M, Q, R) |
| X52 Steel LSAW / DSAW | 16’OD TO 54″ OD (8 MM TO 50 MM THK) |
| Standard | ISO 3183 L390/ API 5L X52 |
| API 5L X52 Seamless Pipe (OD) | 21.3 – 660mm ( Inch 1/2” – 26”) |
| X52 SAW | 16″ – 100″ NB |
| API 5L X52 PSL2 ERW and HFW | 1/2” NB – 24” NB |
| API 5L X52 PSL2 Pipe end | Square Cut, Chamfering, Grooved, Buttweld, Thread Cutting, Squared Ends, Deburring, Flanged Ends, Beveled End (BE), Socket, Cut Grooves, Vibrator Grinding, Coupling, Plain end (PE), Threaded Ends (Male & Female), Pub Joints, Screwed |
| Origin of X52 material | European, Chinese, Africa, Gulf, Asian, Vietnam, Russian, American, Japan, Ukraine, Japanese, Indian, USA, Latin-American, Korean, |
| API 5L X52 Wall Thickness | SCH-STD, SCH160, SCH-XXS, SCH40, SCH-XS, SCH80 |
| Equivalent Standards | JIS, ANSI, EN, DIN, IS, UNI, ISO, AWWA, SS, AISI, NFA, BS, GOST, SA, KS, API, C ASTM, SAE, GB, |
| PSL Level | |
| Coating for API 5L X52 Line Pipe | Galvanized, 3PP, Varnished, 3LPE, lined pipe, Black Painting, 3PE, CRA clad, FBE, Anti-Rust Oil |
| Carbon Steel Grade | Mass fraction, % based on heat and product analyses | Carbon Equiv a | |||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| C | Si | Mn | P | S | V | Nb | Ti | Other | CE IIW | CE Pcm | |||||||||||
| max b | max | max b | max | max | max | max | max | max | max | ||||||||||||
| X52N | 0.24 | 0.45 | 1.4 | 0.025 | 0.015 | 0.1 | 0.05 | 0.04 | d,e,l | 0.43 | 0.25 | ||||||||||
| Pipe Grade | Tensile Properties – Pipe Body of SMLS and Welded Pipes PSL 2 | Seam of Welded Pipe | |||||
|---|---|---|---|---|---|---|---|
| Yield Strength a | Tensile Strength a | Ratio a,c | Elongation | Tensile Strength d | |||
| Rt0,5 PSI Min | Rm PSI Min | R10,5IRm | (in 2in) | Rm (psi) | |||
| Af % | |||||||
| Minimum | Maximum | Minimum | Maximum | Maximum | Minimum | Minimum | |
| X52 | 52,200 | 76,900 | 66,700 | 110,200 | 0.93 | f | 66,700 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| API 5L X52 Pipe types | API 5L X52 Pipe Size (mm) | Tolerances | |
|---|---|---|---|
| Hot rolled API 5L X52 Seamless Pipe | OD | <50 | ±0.50mm |
| ≥50 | ±1% | ||
| WT | <4 | ±12.5% | |
| ≥4～20 | +15%, -12.5% | ||
| >20 | ±12.5% | ||
| Cold drawn API 5L X52 Seamless Pipe | OD | 6～10 | ±0.20mm |
| 10～30 | ±0.40mm | ||
| 30～50 | ±0.45 | ||
| >50 | ±1% | ||
| WT | <1 | ±0.15mm | |
| >1～3 | + 15%, – 10% | ||
| >3 | + 12.5%, – 10% | ||
Dang Steel is a leading supplier of high-quality Carbon Steel API X52 5L PSL 2 Pipes products in Da Nang, Vietnam. We focus on steel solutions and offer a variety of products. This includes Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our products are Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. We are known for our good delivery and excellent customer care. We aim to provide strong and durable steel materials for many industrial uses. We work hard to meet high standards, making us a trusted partner for your steel needs.
Carbon Steel API X52 5L PSL 2 Pipes find extensive use across essential industries thanks to their outstanding performance. They are commonly used in oil and gas pipelines for transporting crude oil, natural gas, and petroleum products. Additionally, they play a vital role in chemical industries, power plants, and water supply systems, where strength and stress resistance are paramount. These pipes are also utilized in both offshore and onshore projects, refineries, and structural applications. Their durability, long service life, and ability to endure harsh environmental conditions make them a preferred choice in many demanding situations.
