Dang Steel, a reputable manufacturer and supplier based in Da Nang, Vietnam, proudly offers top-notch ASTM A709-50W Corten Steel Sheets and Plates. These products are crafted to deliver a perfect blend of strength, durability, and resistance to corrosion. This particular grade of weathering steel is designed to develop a protective rust layer when exposed to the elements, which not only minimizes the need for painting but also extends its lifespan. Known for its outstanding structural performance, ASTM A709-50W is a go-to choice for bridges, buildings, and various outdoor structures. At Dang Steel, we guarantee that our sheets and plates comply with international standards, providing our customers with dependable and cost-effective solutions for long-lasting applications.
The ASTM A709-50W Corten Steel Sheets and Plates are enhanced with copper, chromium, nickel, and phosphorus, which significantly boost their resistance to atmospheric corrosion and overall durability. With a minimum yield strength of 345 MPa and tensile strength ranging from 485 to 635 MPa, this grade showcases impressive mechanical performance. The careful alloying process allows the steel to form a stable oxide layer that shields it from further corrosion. Additionally, these plates are known for their good weldability, machinability, and formability, making them perfect for various fabrication needs. Their unique combination of strength and weather resistance ensures reliable performance in exposed structural applications.
STANDARD: ASTM A709
THICKNESS: 6-100mm
WIDTH: 900-4800mm
LENGTH: 3000-12000mm
GRADES:50W,50WT,50WF
SERVICES: Welding, Forming, Thermal Cutting
| TYPE | THICKNESS (in) | MN (wt %) | C (MAX wt %) | S (MAX wt %) | NI (MAX wt %) | P (MAX wt %) | V (wt %) | SI (wt %) | CR (wt %) | CU (wt %) |
|---|---|---|---|---|---|---|---|---|---|---|
| B | 2.00 – 3.00 | 0.75 – 1.35 | 0.20 | 0.030 | 0.50 | 0.030 | 0.01 – 0.10 | 0.15 – 0.50 | 0.40 – 0.70 | 0.20 – 0.40 |
| A | 0.1875 – 2.00 | 0.80 – 1.25 | 0.19 | 0.030 | 0.40 | 0.030 | 0.02 – 0.10 | 0.30 – 0.65 | 0.40 – 0.65 | 0.25 – 0.40 |
| GRADE | THICKNESS (in) | ELONGATION IN 8″ 2) (MIN %) | TENSILE STRENGTH (MIN ksi) | YIELD STRENGTH 1) (MIN ksi) | ELONGATION IN 2″ 2) (MIN %) |
|---|---|---|---|---|---|
| 50WT | 0.1875 – 3.00 | 18 | 70 | 50 | 21 |
| 50W | 0.1875 – 3.00 | 18 | 70 | 50 | 21 |
| 50WF | 0.1875 – 2.50 | 18 | 70 | 50 | 21 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Dang Steel is one of the most prominent manufacturers and suppliers of superior quality ASTM A709-50W Corten Steel Sheet and Plate in Da Nang, Vietnam. As experts in steel solutions, we supply a complete spectrum of products like Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product range comprises Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Known for our reliable delivery and first-rate customer service, we are committed to supplying high-quality steel materials that guarantee durability and excellent performance in numerous industrial applications.
| GRADE | THICKNESS (in) | MIN LONGITUDINAL INDIVIDUAL VALUE 1) (ft-lbs) | MIN LONGITUDINAL AVERAGE ENERGY 1) (ft-lbs) | ZONE 2 TEST TEMP | ZONE 1 TEST TEMP | ZONE 3 TEST TEMP |
|---|---|---|---|---|---|---|
| 50WT | 2.01 – 3.00 | — | 20 | 40 oF | 70 oF | 10 oF |
| 50WT | 0.1875 – 2.00 | — | 15 | 40 oF | 70 oF | 10 oF |
| 50WF | 0.1875 – 2.00 | 20 | 25 | 40 oF | 70 oF | 10 oF |
| 50WF | 2.01 – 2.50 | 24 | 30 |
| GRADE | WIDTH (in) | THICKNESS (in) | LENGTH (in) |
|---|---|---|---|
| 50WT | 72 – 120 | 0.1875 – 3.00 | 240 – 1200 |
| 50W | 72 – 120 | 0.1875 – 3.00 | 240 – 1200 |
| 50WF | 72 – 120 | 0.1875 – 2.50 | 240 – 1200 |
You’ll find ASTM A709-50W Corten Steel Sheets and Plates commonly used in bridge construction, railway cars, outdoor sculptures, and building facades where both strength and corrosion resistance are essential. They’re also utilized in highway structures, transmission towers, and architectural projects that require an appealing rustic look without the hassle of ongoing maintenance. Thanks to their weathering properties, these materials are particularly advantageous in outdoor settings that face diverse climatic conditions. By cutting down on the need for coatings and frequent maintenance, ASTM A709-50W Sheets and Plates offer significant cost savings and long-term reliability, making them a favored option for both structural and decorative applications.
Dang Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Da Nang, Vietnam.
