Dang Steel, a well-respected manufacturer and supplier based in Da Nang, Vietnam, proudly offers top-notch **Alloy Steel Grade 5 Foils** that are engineered for outstanding strength, corrosion resistance, and precise performance. Crafted using cutting-edge metallurgical techniques and rigorous quality controls, these foils adhere to international standards for reliability and durability. The Alloy Steel Grade 5 Foils from Dang Steel find extensive applications in the aerospace, automotive, chemical, and power generation sectors, where high-performance materials are essential. Thanks to their remarkable mechanical properties, excellent surface finish, and precise thickness control, these foils deliver reliable performance in demanding applications that require high strength, wear resistance, and stability.
**Alloy Steel Grade 5 Foils** primarily consist of chromium (around 18%), nickel (approximately 8%), and molybdenum (about 0.9%), along with carefully controlled levels of carbon, manganese, and silicon. They boast a high tensile strength of roughly 620 MPa, a yield strength of around 290 MPa, and impressive elongation and toughness. These foils are designed to resist corrosion, oxidation, and scaling, while maintaining their structural integrity even at elevated temperatures. Their exceptional mechanical properties and consistent thickness make them ideal for precision applications where strength, durability, and resistance to harsh environments are crucial.
| Specifications | : | ASTM A387 / ASME SA387 |
| Thickness | : | 1mm-300mm |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, 4050mm etc |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, 12000mm, 15000mm etc |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| Alloy Steel Gr 5 | 0.15 max | 0.30-0.60 | 0.5 max | 0.035 max | 0.030 max | 4.0 – 6.0 | 0.45 – 0.65 | – | – |
| Tensile (MPa) | Yield (MPa) | Elongation (50mm) | Elongation (200mm) | Reduction of Area |
| 415 – 585 | 205 min | 18% min | – | 40% min |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
**Alloy Steel Grade 5 Foils** are widely utilized across various industries, including aerospace, automotive, chemical, and power generation. In the aerospace sector, they are used in engine components, turbine parts, and structural elements that demand a high strength-to-weight ratio. The automotive industry incorporates them into exhaust systems, high-temperature components, and precision parts. Chemical plants rely on these foils for heat exchangers, tanks, and pipelines due to their corrosion resistance. Furthermore, power generation industries employ these foils in boilers, turbines, and high-temperature machinery, showcasing their exceptional versatility and performance.
